Beyma 10MC700Nd (8 Ohm) standard | Fs 63 Hz, 94.9 dB, Qts 0.220 | LoudspeakerLab

Thiele-Small parameters

Fs: 63 Hz; Qts: 0.220; Qes: 0.240; Qms: 3.800; Vas: 20.00 L; Sd: 350.0 cm²; Re: 5.20 Ω; Le: 1.00 mH; Sensitivity: 94.9 dB; Nominal Z: 7.6 Ω; Measured range: 20-19455 Hz

Driver quality scores

On-axis flatness 49

Usable passband

Scored passband 100 Hz–2.6 kHz

Measurement coverage

Spec-sheet profiles · Off-axis H/V response data available.

Recommended enclosure

Vented ~5.6 L · Fb 127 Hz

Measurement profiles

• spec sheet (spec_sheet)

Where to buy

• parts_express — $334.50 USD
• soundimports — $206.57 EUR

Measurement quality

LoudspeakerLab evidence grade: C+ (57.0/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.
