Aura Sound NS6-255-8A standard | Fs 55 Hz, 91.0 dB, Qts 0.550 | LoudspeakerLab

Aura Sound NS6-255-8A standard measurements on LoudspeakerLab. 91.0 dB sensitivity. Fs 55 Hz. Qts 0.550. Also known as NS6-255-8A 1m, 1w. Evidence...

Preview

Thiele-Small parameters

Fs: 55 Hz; Qts: 0.550; Qes: 0.580; Qms: 10.800; Vas: 16.48 L; Sd: 126.0 cm²; Re: 6.00 Ω; Sensitivity: 91.0 dB; Nominal Z: 6.5 Ω; Measured range: 20-19612 Hz

Driver quality scores

On-axis flatness 77 · THD 84

Usable passband

Scored passband 143 Hz–1.3 kHz

Measurement coverage

Distortion measurements · Measured profiles

Recommended enclosure

Vented ~27.0 L · Fb 46 Hz

Measurement profiles

Measurement quality

LoudspeakerLab evidence grade: B+ (75.2/100). Based on measurement provenance, off-axis data, distortion, and T/S completeness.

Also known as

NS6-255-8A 1m, 1w
