Wavecore/SB/RSS Tower - LoudspeakerLab Design

Design summary

Preference rating 7.6 · F3 23 Hz · Max SPL 98 dB at 1 kHz · Min impedance 3.2 Ω · Sensitivity 77.6 dB · Estimated cost USD 413

Drivers

• SB Acoustics SB15NBAC30-4 (midrange)
• Wavecor Wavecor TW030WA14 (tweeter)
• Dayton Audio RSS210HF-4 (woofer)

Enclosure

Baffle 272 × 965 mm
